Описание
Технические характеристики согласно ETIM 6.0
Low-voltage industrial components (EG000017) / Fuse switch disconnector (EC001040) | |||
Electric engineering, automation, process control engineering / Low-voltage switch technology / Off-load switch, circuit breaker, control switch / Fuse switch disconnector (ecl@ss8.1-27-37-14-01 [AKF058010]) | |||
Version as main switch | No | ||
Version as safety switch | No | ||
Max. rated operation voltage Ue AC | V | 690 | |
Rated permanent current Iu | A | 32 | |
Rated operation power at AC-23, 400 V | kW | 0 | |
Conditioned rated short-circuit current Iq | kA | 100 | |
Rated short-time withstand current lcw | kA | 0.3 | |
Suitable for fuses | Shape C1-C3 | ||
Number of poles | 3 | ||
With error protection | No | ||
Type of electrical connection of main circuit | Screw connection | ||
Suitable for ground mounting | Yes | ||
Suitable for front mounting 4-hole | No | ||
Suitable for busbar mounting | No | ||
Type of control element | - | ||
Position control element | Front side | ||
Motor drive optional | No | ||
Motor drive integrated | No | ||
Version as emergency stop installation | No | ||
Degree of protection (IP), front side | IP20 |
Данный товар вы всегда сможете купить по низкой цене с доставкой у нас в магазине МВБ по номеру телефона 8 495 185-05-44 или написав на почту zakaz@security-master.ru
Характеристики
Номинальный ток, А
32
|
